China suppliers DPP250 PVC aluminum CBD foil Tablet Capsule Oil Honey Liquid Jam Butter Blister Packing Machine

  • >=1 Sets
    $12,300.00
Power:
11KW
Model Number:
DPP-250
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 40 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Graphic customization (Min. Order: 1 Sets)

More

Customized packaging (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 Year
Automatic Grade:
Automatic
Dimension(L*W*H):
3300*950*1700MM
Type:
Blister Packaging Machine
Applicable Industries:
Food & Beverage Factory, Food Shop, Food & Beverage Shops, Advertising Company
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Driven Type:
Electric
Voltage:
220V/380V
Place of Origin:
China
Brand Name:
SINOPED
Weight:
1800 kg, 1800kg
Certification:
CE/GMP/IOS
Key Selling Points:
High-accuracy
Name:
DPP250 PVC aluminum CBD foil Tablet Capsule Blister Packing Machine
Forming film:
PVC/PVDC
Cooling system:
Cooling water
Power of main motor:
2.2KW 380V/50Hz
Forming speed:
60/min
Cutting speed:
120/min
Packing speed:
depend on being packed material
Air Consumption:
0.3m3/min 0.6MPa
Power:
11KW
After-sales Service Provided:
Free spare parts, Field installation, commissioning and training, Video technical support, Online support
Packaging & Delivery
Packaging Details
Packing for DPP250 PVC aluminum foil Tablet Capsule Oil Honey Liquid Jam Butter Blister Packing Machine:
Inner Package:Stretch film
Outter Package:Wooden Case
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 40 To be negotiated
Video Description
Product Description

Product Application

1.The design of DPP250 PVC aluminum foil Tablet Capsule Oil Honey Liquid Jam Butter Blister Packing Machine is novel and reliable. Its packing efficiency is the highest among the like products at present.
2.Unique position adjustment structures ensure line breaking clearly.No-edge cutting can save the cost of packing materials.
3.The cutted plates will be taken out by a placing arm, that uses a vacuum.
4.PLC and printing adjustment structure make operational work easier.
5.Cutting Frequency:20-180/p.m.172 ten thousands pills/each working shift(10pills/per board:8 hrs/each working shift.
6.Beautiful appearance overall, all are built and covered with stainless steel, fully sealed and conformed to the standards of GMP pharmaceutical production. The product is reliable in quality, smooth in operation. The shapes formation can be selected according to different production scales.

DPP250 PVC aluminum foil Tablet Capsule Oil Honey Liquid Jam Butter Blister Packing Machine
Cutting Frequency (Times/min)
6-50
Production Capacity (pcs/h)
35000-230000
. Forming Area And Depth (mm)
240×150×26 (Standard Depth 14mm)
Travel Range (mm)
40-130(Can be customized)
Standard Plate (mm)
80×57(Can be manufactured as user's requirements)
Air Pressure (Mpa)
0.4-0.6
Air Supply
≥0.35m3/min
Total Power
380V/220V 50Hz 6.2KW
Overall Dimensions (mm)
3000×730×1600(L×W×H)
Weight (kg)
1600kg

Main Features

1.Plate-model pressure blowing positively for the blister formation and hot seal as well as high efficiency in packing;
2.Can be matched to be in set of filling devices such as universal filler, converting head filler, disk vibrating filler;
3.Man-computer interfacing PLC control, F-converting speed, high speed cutting ranged from 20 to 180/pm: Note: Times in cutting depend on the plate's length;
4.Heating: inner hearing, auto-control;
5.Long length filling platform, highlight finishing rate, and also can be installed with conveying belt;
6.Cooling: circulating water, or otherwise using the tap water (outgoing connection);
7.Cutting without waste Left, saves the packing material up to 10%.

Detailed Images
Other Products

Why choose us?

1. SINOPED has been engaged in the purification technology and application. And we have the R&D team, performing continuous product research and improvement from time to time.
2. Our products are certificated by the most prestigious national and international institutes.
3. Each procedure of the production process is conducting under the strict quality control system. Our QC inspects each lot of the incoming material and the finished products carefully, so that we can supply the best products for customers.
4. From the design to the producing, each procedure is controlled strictly, so we can control the product costs optimally, and offer products with the best quality and the most competitive price. Win-win is our ultimate purpose.

Packing & Delivery
Our Service & FAQ

One-year warranty period for whole machine except of tubes and human factors etc, and 12-month of after-sale service from the date when you receive machine or 12 months when installation finished;
Consultant services for whole machine life, and 24 hours technical support by email;
UPS, English software, user manual and the installation & debugging by our experienced technicians.

1. Can your machine meet our need well?
We will supply you a proposal as to your specific requirement, and each machine is customized to satisfy customer's need well.
2. Are you a factory or a trading company?
We are the manufacturer, and have been in industry for more than ten years.
3. What's your payment way?
T/T by our bank account directly, or by Alibaba's trade assurance service, or by the West Union, or in cash.
4. How can you ensure the machine's quality after we put the order?
Before the delivery, we will send you machine's pictures and videos, or you can come to us to have the quality checking by yourself, or by the third party inspection organization contacted by your side.
5. We are afraid you won't deliver us the machine after we pay you the money.
Please note our above business license and certificates. And if you don't trust us, you can use Alibaba's trade assurance service or by LC.
6. Why choose your company?
We have been engaged in the manufacturing of various packing machines professionally over 10 years, and we can provide better after-sales service.

Feedback
Our Company

Sino Pharmaceutical Equipment Development (Liaoyang) Co., Ltd. (SINOPED) is a professional manufacturer and supplier of pharmaceutical and chemical machinery and equipment in China. We belong to SINOPEC International Group.
We have a well-experienced team to manufacture pharmaceutical machinery and equipments and a professional design institute. With rich experiences in pharmaceutical machinery and equipment field and numbers of professional engineers, we have designed and developed many types of machinery and equipments including clean room project, soft-gel production line, glass-lined reactor, fermentor, centrifuge, granulator, mixer, dryers, pulverizer, tablet press, soft and hard blister packing machine, capsule filling machines, cartoner and rollers, etc.
Due to our good credit and service, , we have made great achievements in the past years. We have established long-term business relations with many customers and some of our overseas customers have appointed us to be their purchase agency in China. Our products are exported to many countries & areas, such as Korea, India, Indonesia, Pakistan, Thailand, Vietnam, Iran, Japan, Denmark, Romania, Bulgaria, Russia, South Africa, Nigeria, the USA, Australia, Canada, Argentina and Chile. Besides machinery and equipment, we also supply production lines and turn key projects.
In SINOPED you can get your desired goods with the best prices and good quality. Welcome your enquiries from all over the world.
